Form factor |
2U Rack. |
|
Processor |
Intel Xeon Processor E5-2609 v3 6C 1.9GHz 15MB Cache 1600MHz 85W
Up to two Intel Xeon processor E5-2600 v3 product family CPUs with 18 cores (2.3 GHz core speeds) or up to 12 cores (up to 2.6 GHz core speeds). Two QPI links up to 9.6 GT/s each. Up to 2133 MHz memory speed. Up to 45 MB L3 cache.
|
|
Chipset |
Intel C612. |
|
Memory |
8GB TruDDR4 Memory (2Rx8, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM
Up to 24 DIMM sockets (12 DIMMs per processor). RDIMMs and LRDIMMs are supported. Memory types cannot be intermixed. Memory speed up to 2133 MHz.
|
|
Memory maximums |
-
With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors
-
With LRDIMMs: Up to 1.5 TB with 24x 64 GB LRDIMMs and two processors (support for 64 GB LRDIMMs is planned for a later date)
|
|
Memory protection |
ECC, and Chipkill. |
|
Disk drive bays |
Up to 26x 2.5" hot-swap SAS/SATA drive bays, or up to 14x 3.5" + 2x 2.5" hot-swap SAS/SATA drive bays, or up to 16x 2.5" Simple Swap SATA bays, or up to 8x 3.5" Simple Swap SATA bays. |
|
Maximum internal storage |
Up to 31.2 TB with 1.2 TB 2.5" SAS HDDs, or up to 26 TB with 1 TB 2.5" NL SAS/SATA HDDs, or up to 24.3 TB with 960 GB 2.5" SATA SSDs, or up to 86.4 TB with 6 TB 3.5" NL SAS/SATA HDDs and 1.2 TB 2.5" SAS HDDs. Intermix of SAS/SATA is supported. |
|
Storage controller |
-
Onboard 6 Gb SATA: no RAID support
-
12 Gb SAS/SATA RAID: RAID 0, 1, 10 with M1215 or M5210. Optional upgrade to RAID 5, 50 is available for M1215. Optional upgrade to RAID 5, 50 is available for M5210 (zero-cache; 1 GB non-backed cache; 1 GB, 2 GB or 4 GB flash-backed cache). Optional upgrade to RAID 6, 60 is available for M5210 with memory cache upgrades.
-
12 Gb SAS/SATA non-RAID: N2215 HBA
|
|
Optical drive bays |
One for models with 8x 3.5" or up to 16x 2.5" drive bays (models with 24x 2.5" or 12x 3.5" drive bays do not support an internal optical drive). Support for DVD-ROM or Multiburner. |
|
Tape drive bays |
None. |
|
Network interfaces |
Four integrated RJ-45 Gigabit Ethernet 1000BASE-T ports (BCM5719); optional Mezzanine LOM (ML2) slot for dual-port 10 GbE cards with SFP+ or RJ-45 connectors or quad-port GbE cards with RJ-45 connectors. |
|
PCI Expansion slots |
Up to nine slots. Slots 0, 4, and 5 are the standard slots on the system planar, and the remaining slots depend on the riser cards installed. The slots are as follows:
-
Slot 0: PCIe 3.0 x8 (dedicated for an internal RAID controller)
-
Slot 1: PCIe 3.0 x16 or PCIe 3.0 x8; full-height, full-length (PCIe x16 slot is double-wide)
-
Slot 2: PCIe 3.0 x8; full-height, full-length (not present if the slot 1 is PCIe x16)
-
Slot 3: PCIe 3.0 x8 or ML2; full-height, half-length
-
Slot 4: PCIe 3.0 x8; low profile (vertical slot on system planar)
-
Slot 5: PCIe 3.0 x16; low profile (vertical slot on system planar)
-
Slot 6: PCIe 3.0 x16 or PCIe 3.0 x8; full-height, full-length (PCIe x16 slot is double-wide)
-
Slot 7: PCIe 3.0 x8; full-height, full-length (not present if the slot 6 is PCIe x16)
-
Slot 8: PCIe 3.0 x8; full-height, half-length
Slots 5, 6, 7, and 8 require the second processor to be installed. |
|
Ports |
-
Front: 2x USB 2.0, 1x USB 3.0 (8x 3.5" and up to 16x 2.5" drive bay models), and 1x DB-15 video.
-
Rear: 2x USB 3.0, 2x USB 2.0, 1x DB-15 video, 1x RJ-45 systems management, 4x RJ-45 GbE network ports. Optional 1x DB-9 serial port.
-
Internal: 1x USB port (for embedded hypervisor).
|
|
Cooling |
IBM Calibrated Vectored Cooling with up to six redundant hot-swap fans (four standard, additional two fans with the second processor); two fan zones with N+1 fan redundancy; each fan has two motors. |
|
Power supply |
System x 550W High Efficiency Platinum AC Power Supply
Up to two redundant hot-swap 550 W, 750 W or 900 W High Efficiency Platinum AC power supplies, or 750 W High Efficiency Titanium AC power supplies.
|
|
Video |
Matrox G200eR2 with 16 MB memory integrated into the IMM2.1. Maximum resolution is 1600x1200 at 75 Hz with 16 M colors. |
|
Hot-swap parts |
Hard drives, power supplies, and fans. |
|
Systems management |
UEFI, IBM Integrated Management Module II (IMM2.1) based on Renesas SH7758, Predictive Failure Analysis, light path diagnostics, Automatic Server Restart, IBM ToolsCenter, IBM Systems Director and Active Energy Manager. Optional IBM Integrated Management Module Advanced Upgrade software feature for remote presence. |
|
Security features |
Power-on password, administrator's password, two Trusted Platform Modules (TPMs): on the IMM2 (TPM 1.2) and on the host (TPM 1.2/2.0). Optional lockable front bezel. |
|
Operating systems supported |
Microsoft Windows Server 2012 R2, 2012 and 2008 R2, Red Hat Enterprise Linux 6 and 7, SUSE Linux Enterprise Server 11, VMware vSphere (ESXi) 5.1 and 5.5. |
|
Limited warranty |
Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD). |
|
Service and support |
Optional service upgrades are available through IBM ServicePac®: Four-hour or two-hour response time, eight-hour fix time, one-year or two-year warranty extension, remote technical support for IBM hardware and some IBM and third-party applications. |
|
Dimensions |
Height: 86.5 mm (3.4 in), width: 445.6 mm (17.5 in), depth: 800 mm (31.5 in) |
|
Weight |
Minimum configuration: 19 kg (42 lb), maximum: 34 kg (75 lb) |
|
|
